Alfatronix Converter DD 12V DC - 24V DC 25A Ruggedised


Alfatronix Converter DD 12V DC – 24V DC 25A Ruggedised


Alle Preise sind exkl. MwSt


Bitte anrufen wegen Lieferung
Bestellung aufgeben und Kasse abschließen. Wir bieten die Lieferzeit innerhalb von 24 Stunden.

12 V DC – 24 V DC,  robust

Eingangsspannungsbereich 17-32V DC
Ausgangsspannung 13,6V DC
600 Watt § 25A

Robustes Gehäuse für raue Umgebungen.

Einfache Montage mit “Click’n’ Passform” Befestigungsclip

Geschützt vor Staub, Wasser und Stößen nach IP65

ALFATRONIX bietet lebenslange Garantie

Eingangsspannung12V DC
Ausgangsspannung24V DC
Output Power600W
Gewicht (kg)2.340
Länge mm271.00
Breite mm125.00
Höhe mm74.00

Mehr über das Produkt


Harsh Environments

These products offer the same great electrical characteristics as our PowerVerter and DD Series, but are provided in ‘Ruggedised’ casings for use in harsh environments. Using the well-known Ingress Protection System, the product range has been tested and subjected to demanding environmental conditions and awarded a rating of IP655.

All Ruggedised PowerVerters are enclosed in a durable aluminium extrusion. The low mass Surface Mount Technology components are also less prone to damage from vibration and shock, further increasing the reliability of the units.

Innovative Technology

Utilising the same GORE-TEX® technology that is used in extreme outdoor clothing, the Ruggedised range is able to breathe freely, without compromising the water tight and dust tight seal. This free-flow of air ensures that the pressure remains equal inside and outside the unit thus allowing it to operate within a large temperature range and at varying altitudes safely.

Fast Installation

All the products fit onto a ‘Click ‘n’ Fit’ mounting clip which is fixed in three points allowing it to be mounted on uneven surfaces. It is easy to fit the clip into awkward places, and then simply click the unit into position.


As well as being dust and water tight to IP65 the units are vibration resistant. They have an anti-vibration cable gland fitted into a hexagonal recess to prevent unwanted knocks from loosening it, so they can be fitted into rugged environments care-free.

Additional Features

The RU range has the same features as the standard PV & DD range, but in addition, they also offer the following benefits:

· Dust, water and impact resistant to IP655

· Breathable vent to prevent unwanted build up of pressure

· Anti-vibration cable gland

· Supplied with 1m of cable as standard

Product Variants

Many PowerVerter-RU and DD-RU Series products can be configured with alternative output voltages etc, for specialist applications. Please call our sales team to discuss your requirements.


DD DC input and output
1224 Nominal  12V input, 24V output
600 600W capacity unit
RU Ruggedised
